High Performance Plastics
HT-90 Material 3D Parts Service
Material Overview
HT90 3D printing material is a strong and transparent rigid for applications requiring temperature resistance and/or biocompatibility, ideal for rapid tooling, functional prototyping in warm environments, and medical devices with fine features and internal structures. This transparent material is also capable of meeting USP Class VI standards for biocompatibility, to be used for printing medical devices where biocompatibility is required and fine features and small internal structures are needed for lattice structure or fluid flow channels.
Common Applications
Molds and dies for rapid tooling applications, functional testing in warm environments like: under-the-hood components, heated fluids and gasses flow analysis and electronics enclosures/cases
Key Material Properties
High Temperature
Bio-Compatible
Transparent Material
Flexural Strength (MPA) 105 - 120
Elongation at Break % 4 - 9
HDT at 0.4555 MPA 90 - 100°C
Maximum Part Size 294 x 211 x 144 mm (11.6 x 8.3 x 5.6 in)
Layer Thickness Options - High Resolution, Ultra-High Resolution
What part file formats are supported?
stl, stp, step, obj and wrl
What is the 3D printing process for this material?
HT90 3D printing material is produced using 3D Systems ProJet 2500 3D printing technology. This technology jets layers of UV curable liquid plastic onto a flat platform. Wax support material is also jetted to fill voids and other non-freestanding features. UV lamps flash to solidify material creating a fully cured plastic part. Accuracy of the 3D Systems Projet 2500 3D printing technology is dependent on factors such as part geometry, part size, and post processing among other factors, but is approximately +/-0.1 mm (0.004 in).
Will there be support scarring on this part?
One of the main benefits of the ProJet 2500 3D printing technology from 3D Systems is accuracy and also support removal. The ProJet 2500 utilizes wax support material during the 3D printing process. During post processing the wax is simply melted away, leaving the cured plastic part with no support scarring. This also leaves small, delicate part features intact as well.
How long will it take before I receive my part in this material?
Production times vary depending on machine availability, but generally HT90 3D parts are printed and shipped within 3-5 business days.
Upload A File To Get Started
