High-Quality UV-LED Printing Without the High Cost
The UJV200 Series brings Mimaki's flagship "330 Engine" print head down to an entry-level roll-to-roll UV-LED printer, so shops get high-end image quality without the high-end price. Instant UV curing eliminates the wait before and after printing, while avoiding the high heat latex systems need — which keeps power consumption down and media compatibility wide open.
Beautiful color solids and smooth skin tones come from Variable Dot Technology and MAPS4, sharpened further by a new DAS2 dot adjustment system. The result is stable multi-layer printing without pullback, strong abrasion resistance for floor graphics, and support for high-value clear-ink applications — all from low-odor, SVHC/CMR-free ink.
Flagship Engine, Entry-Level Price
The same print head technology found in Mimaki's high-end printers, scaled into an accessible roll-to-roll machine.
330 Engine Single Printhead
Flagship-level image quality with sharper fine lines from the new DAS2 dot adjustment system — no expertise required to dial in.
Instant UV-LED Curing
No drying or curing delays, and no high heat required — print directly on heat-sensitive media while keeping power consumption low.
Stable Multi-Layer Printing
White and clear ink support up to 3-layer printing without pullback, plus excellent abrasion resistance for floor graphics.
Low-Odor, SVHC/CMR-Free Ink
The UJV200 Series runs on next-generation UV ink that's safer for people and the environment — roughly 30% less odor than before, with no SVHC or CMR substances. That makes it a practical fit for occupied indoor spaces like offices, retail stores, and hospitality venues, with same-day turnaround from print to install thanks to instant curing.
- Approx. 30% less odor than previous-generation ink
- SVHC-free and CMR-free formulation
- Safe for occupied indoor environments
Ink Types
ELS-170
Next-generation UV ink built for safety and flexibility, with the lowest odor in the lineup.
LUS-210
A cost-effective option for shops prioritizing production economics over the newest ink chemistry.
Two ink options let shops match performance to budget without changing machines — ELS-170 for the newest safety standard, LUS-210 for lower-cost production runs.
RasterLink Included
Production-Ready Workflow Tools
Supports variable data printing, PANTONE® matching, step & repeat, ID-Cut print-and-cut integration, ink saving, and multi-printer control — everything needed for professional UV roll-to-roll printing in one package.
Full Specifications
Print & Ink
| Print Head | On-demand piezo print head (single) |
| Print Resolution | X: 600/1200 dpi — Y: 600/900/1200 dpi |
| Print Speed (4 Color Mode) | 183 sq ft/hr (17 m²/hr) |
| Ink Type | SS22 Eco-Solvent (C, M, Y, K, Lc, Lm, Lk, Or) |
| Ink Package | 440ml cartridges / 1L bulk (optional Mimaki Bulk Ink System) |
Media & Print Area
| Max. Print Width (JV200-130) | 53.6 in (1,361 mm) |
| Max. Print Width (JV200-160) | 63.4 in (1,610 mm) |
| Max. Media Width | 53.9 in (1,371 mm) / 63.8 in (1,620 mm) |
| Media Thickness | Up to 0.04 in (1 mm); printing gap manual, two settings (1.5, 2.0 mm) |
| Media Weight | 55 lb (25 kg) with option |
Power & Environment
| Power Supply | AC (100–120V / 200–240V ±10%) × 2, 50/60Hz ±1Hz |
| Power Consumption | Max. 1,320W ×2 | Sleep mode: 4.5W |
| Operating Temp. | 68–86°F (20–30°C) |
| Operating Humidity | 35–65% |
Interface, Certifications & Dimensions
| Interface | USB 2.0 Hi-speed / Ethernet 1000 BASE-T |
| Certifications | VCCI Class A, FCC Class A, ETL IEC 62368-1, CE Marking (EMC/LVD/Machinery/RoHS), CB, REACH, Energy Star, RCM, EAC, KC, UKCA |
| Dimensions (JV200-130) | 2,520 × 748 × 1,370 mm |
| Dimensions (JV200-160) | 2,770 × 748 × 1,370 mm |
| Weight (uncrated) | 129 kg (130) / 135 kg (160) |
