Industrial-grade UV DTF printer built for high-precision direct-to-film printing on complex surfaces. The CJV200 Series delivers 1200dpi output across 640mm width, transferring crisp designs onto helmets, mugs, cylinders, and irregular geometries without manual finishing.

Dual ink system switches between CMYK and White/Clear configurations to match your production requirements. Automatic maintenance keeps nozzles primed and white ink circulating for consistent, uninterrupted runs.

GREENGUARD Gold certified for low VOC emissions. Purpose-built for custom merchandise, signage, labels, decals, and specialized manufacturing where surface irregularity and print quality are non-negotiable.

One Printer to Do It All

The CJV200 Series pairs an entry-level eco-solvent printer with an integrated cutter, giving small shops indoor and outdoor durable printing plus finishing in a single, small-footprint device. It's a total sign printing package — print & cut device, software, and a range of inks — at an attractive price point.

Available in 32", 54", and 64" widths, the CJV200 reaches production speeds up to 183 sq ft/hr while running on GBL-free SS22 ink for improved operator safety. Paired RIP software handles the precision needed for instant decals and large wall graphics.

Print and Cut, Without the Complexity

A streamlined single-head design that keeps maintenance simple without giving up production capability.

1

Integrated Print & Cut

A single-head, single-machine workflow eliminates the need for a separate cutter — easy to work with, easy to check, easy to maintain.

2

SS22 GBL-Free Ink

Available in 4- or 8-color configurations, with an ink-saving function that cuts consumption up to 43% without needing a new media profile.

3

ID-Cut Finishing

RasterLink7's barcode-based ID Cut function delivers extreme accuracy for instant decals and large wall graphics.

GBL-Free Ink, Industry-Best Outdoor Durability

SS22 ink is free of GBL (gamma-butyrolactone), a controlled substance, for improved operator safety, and ships in an environmentally friendly paper cartridge. Combined with the CJV200's core technologies, it delivers the industry's best outdoor color durability at an entry-level price.

  • GBL-free SS22 ink for operator safety
  • Industry-best outdoor color durability
  • Eco-friendly paper cartridge packaging
GBL-Free Ink SS22 eco-solvent formulation
GREENGUARD Gold Certified eco-solvent ink

Ink Types

SS22 — 4-Color

Cyan, Magenta, Yellow, Black. The standard configuration for everyday signage and decal production.

SS22 — 8-Color Extended

Adds Light Cyan, Light Magenta, Light Black, and Orange for an expanded gamut on higher-value jobs.

Both configurations run on the same GBL-free ink chemistry, so shops can start with 4-color and expand into 8-color as demand grows.

RasterLink7 Included

ID-Cut & Remote Monitoring

RasterLink7's barcode-based ID Cut finishing pairs with Mimaki PICT, a cloud-based printer status monitoring tool, so operators can track production and performance from a PC or mobile device.

dcd067f90f8ec72c2ed66aaeba27ddfc84c2611e1e78aeccda51f12ffd6591b5

Full Specifications

Covers CJV200-75, CJV200-130, and CJV200-160 models

1610mmPrint Width
1200dpiMax Resolution
105–140kgWeight
440mlInk Cartridge
🖥 Print & Ink
Print HeadOn-demand piezo print head (single)
Print ResolutionX: 600/1200 dpi — Y: 600/900/1200 dpi
Print Speed (4 Color Mode)183 sq ft/hr (17 m²/hr)
Ink TypeSS22 Eco-Solvent (C, M, Y, K, Lc, Lm, Lk, Or)
Ink Package440ml cartridges / 1L bulk (optional Mimaki Bulk Ink System)
📜 Media & Print Area
Max. Print Width31.5 in (800 mm) / 53.6 in (1,361 mm) / 63.4 in (1,610 mm)
Max. Media Width31.9 in (810 mm) / 53.9 in (1,371 mm) / 63.8 in (1,620 mm)
Media ThicknessUp to 0.04 in (1 mm)
Rolled Media Weight55 lb (25 kg)
Power & Environment
Power SupplyAC (100–120V / 200–240V ±10%) × 2, 50/60Hz ±1Hz
Power ConsumptionMax. 1,320W ×2 | Sleep mode: 4.5W
Operating Temp.68–86°F (20–30°C)
Operating Humidity35–65%
🛠 Interface, Certifications & Dimensions
InterfaceUSB 2.0 Hi-speed / Ethernet 1000 BASE-T
CertificationsVCCI Class A, FCC Class A, ETL IEC 62368-1, CE Marking (EMC/LVD/Machinery/RoHS), CB, REACH, Energy Star, RCM, EAC, KC, UKCA
Dimensions1,960 × 748 × 1,370 mm / 2,520 × 748 × 1,370 mm / 2,770 × 748 × 1,370 mm
Weight (uncrated)105 kg / 130 kg / 140 kg
